The Metavision-1008i3 spectrometer provides high resolution and low detection limits for elements with high accuracy and repeatability, setting new standards for metal spectral analysis for the metallurgical industry.
Optical Emission Spectrometers The Metavision 1008i3 spectrometer provides high resolution and low detection Limits for elements with high accuracy and repeatability, making it the new standard for metal spectral analysis for the metallurgical industry.
The device can be C, N,O, Li, Na, S, P, etc. It can analyze more than 55 elements, including 1 ppm, with low detection limits.
Metavision-1008i3 is ideal for quality-oriented users.
Based on CMOS / CCD detectors, it does not need hardware upgrade and software update, even if new elements, bases or matrices need to be added after purchase of the spectrometer!
Optical Emission Spectrometers The Metavision 1008i3 spectrometer features ultra-high resolution dual optics, uses the latest generation of CMOS detectors and specially designed optical components that directly lead to lower detection limits and higher stability than other OES in its class.
In addition, the entire optical system is hermetically sealed and thermally stabilized to a low temperature, which minimizes thermal noise and further improves performance.
The 130-671 nm Metavision-1008i3 spectral range covers most of the element lines. The instrument can analyze more than 55 elements by base in standard configurations – and with the possibility to add additional bases and Matrices.
Optical Emission Spectrometers Metavision provide spectral resolution of up to 7 pcm and the use of specially designed components and applications make it the only instrument in its class to offer extremely high accuracy oxygen analysis at low levels (down to 10 ppm).
The instrument also provides analysis of low detection limits for all alloying elements, including C, S, P, B, Ni, Cr, Li, Na, etc. which makes it an ideal solution for any business.
For any spectrometer, the quality and stability of the analyzes are closely related to the quality of the power supply and the stability of the current discharge.
Additionally, the ability to customize the output is crucial to ensure the analysis is optimized for each item.
The device is equipped with a powerful and at the same time very compact excitation source with digital current control, providing the highest level of accuracy and stability.
Through computer control of each parameter, the power supply provides the highest level of plasma stability and the ability to produce ideal spectra for a variety of analytical programs.
Metavision-1008i3 is designed to be very easy to maintain. The device is fully modular in design and has optimized the isolation of subsystems to provide easy access to the engineer for maintenance and to the user for daily tasks.
The design also ensures that subsystems are not at risk during cleaning and replacement of any materials, etc.
Metavision-1008i3 offers ultra-fast analysis and uses vacuumless optics. This eliminates continuous cleaning, reducing argon consumption to the lowest levels.
The device can also be easily upgraded. At any time, you can add additional databases and materials to meet the needs of your current tasks and allow the analytics system to grow as the business evolves.
This provides optimum investment protection and best-in-class analysis and ownership costs at every stage of the instrument lifecycle.
It’s not just the design and feature set that matters to users, it’s usability as well. For this purpose, Metal Power has developed programs for Metavision-1008i3 that meet almost all user needs.
For example, considering the requirements of manufacturers of oxygen-free electrolytic copper, the device provides detection limits for oxygen as low as 10 ppm (0.001%), making users only need one device to cover the entire chemical spectrum.
Similarly, Metavision-1008i3 has low detection limits in the range of 1-10 ppm for almost every major element in steel (including C, S, P, B, Mo, V, Al, etc.) as well as low detection rates. N and O; It offers Li and Na ppm detection required by manufacturers in the aluminum industry, and low-level cobalt detection to meet battery manufacturers’ requirements.
It also now offers “Master Alloy” calibration to meet the needs of alloy manufacturers who can accurately assess both major and trace elements in master alloys.
Metallurgical plants and alloy manufacturers require analysis of the widest element range of 1-10 ppm, even at very low levels, as well as the highest level of accuracy and repeatability.
The instrument can analyze C, O, N, S, P down to very low levels with high repeatability. Metavision-1008i3 meets all these and many other requirements. The ability to analyze thin wire and thin foil also makes the metavision-1008i3 spectrometer an extremely valuable proposition for users.
Manufacturers of pure metals such as lead, zinc, copper and titanium require extremely low detection Limits for almost any element, including heavy elements such as lead, arsenic, cadmium, to meet environmental standards as well as purity requirements.
Metavision-1008i3 offers low detection Limits allowing metals to be analyzed with extremely high accuracy up to 99.99%.
For producers of pure copper and titanium, the possibility of oxygen analysis enables accurate determination of even oxygen-free and electrolytic copper, as well as meeting the needs of all titanium grades.
Commercial laboratories serve a range of industries by analyzing several hundred samples per day for a wide variety of metals and alloys. For such laboratories, the availability of a spectrometer with high efficiency, low operating costs, a wide variety of elements and sensing is important to perform a variety of tasks.
| Main features: | Multi-optical system using the latest generation of high resolution detectors. |
| Wavelength range: | up to 130-671 nm. |
| Focal length: | Up to 400mm. |
| Spectral resolution: | Up to 7 pkm(1pkm=10^(-12) m/10^(-3) nm). |
| Optical: | Cooled low temperature, heat resistant optics. |
| Power supply: | Power supply is digitally controlled. |
| Power: | 90-270 V AC; 50/60Hz. |
| Accessories and options: | Adapters for analysis of rods of various cross-sections and wires. Equipment for sample preparation of samples. Certified standard samples (CRM) Argon cleaners. |
| Brand | MetalPower |
|---|
Founded in 1987, Metal Power offers a comprehensive range of products, applications and services to meet the analytical needs of the metals industries. Part of our products:
Alongside its product range, Metal Power, through its Laboratory Division, also offers:
Today the Company has over 30 years of experience serving the needs of the ferrous and non-ferrous metals industries and has a truly global presence spanning over 35 countries across 5 continents. The common denominator across all of our offerings (products, applications and services) is our commitment to deliver the highest levels of quality, reliability and uptime while also delivering the lowest cost throughout the product lifecycle through low purchasing costs backed by the highest quality. We offer service and after-sales support to our customers anywhere in the world.
Our solutions help our customers improve the quality of their products, while also delivering continuous cost savings and revenue growth through material cost savings, elimination of rejects, dramatic improvements in productivity and, of course, the research and development of newer materials and alloys. Today, our equipment powers many leading companies in industry sectors and geographic markets. With a rapidly expanding base of already over 2,300 customers, we are today the largest OES firm in India and one of the fastest growing companies in the world.
